Four shaft shredders, or name it quad shredders, are perfectly suitable for scrap size reduction applications such as e-waste, rubber tire recycling, RDF production, and contaminated materials where uniformed medium particle size is desired. The four shaft shredders are very robust and built to sustain tough operating conditions without problem.

Get Quote

Main Features

▶ Larger cutting chamber and less material bridging possibility

▶ Underneath screen for uniform particle size

▶ More knives for easier grabbing of material

▶ Double dust and water proof protects bearings and gears

▶ Maximized cutter arrangement for better shredding result

▶ Repairable blades and easy maintenance

▶ PLC with monitor control for to and fro rotation

Blade Thickness25-50mm

Shredding Chamber900-2000mm

Motor Power18.5*2 – (45*2+30*2)kw

Exclusive selling points

Four Shafts Shredder

01Detachable Box
The shredding chamber body can be deconstructed from each end of the coupling. The main shaft can be detached as a whole by removing the mounting plate at each end of the bearing.
Once the main shaft is dismantled,the cutter body and bearings can be kept and inspected,and if need be,then it can be replaced as well.
Regarding the processing ofthe shredding chamber,care should be taken to position the main shaft and bearing at central position during installation to ensure that the structure remains intact and lasts longer.
02Heavy-load Planetary Reducer
It has a box of rigid casting reducer consisting of gussets.
The sturdy finishing gear is composed of high-quality steel alloy,and the surface is processed through carburizing and quenching methods.
Then,the structure is finely processed by means of gear grinding.This through process ensures many operational benefits,such as stable transmission power, low noise and greater carrying capacity.
03Detachable Cutter
Detachable blade design greatly reduces blade replacement time A complete crushing blade comprises of three parts.
It is quite easy to replace a worn blade: simply loosen and tighten the bolt.
04Electric System
The electric cabinet is equipped with a Siemens/Schneider PLC.
The electric cabinet boasts a touch screen with a high capability of promoting human-machine interaction.
Siemens/Schneider electrical components are adopted.
05Sealing System
The bearing has a quadruple sealing protection design which makes it dust proof and waterproof, effectively prolonging the service life of the bearing.
Therefore,it can work excellently in an outdoor, highly dusty environment.
06Auxiliary System
A pressing device is optional.It can help to crush materials rapidly.
A rotating screen is optional,and it guarantees dimensional uniformity of crushed products.
07Splined Main Shaft
The moving blade base and the main shaft align in spline transmission.
The design consist of a large surface junction without stress concentration.The spiral.
Configuration of the moving blade base can enhance its crushing efficiency and reduce energy consumption.
The moving blade base has been tested by using 100% ultrasonic and non-destructive inspection to maximize the cutter's crushing capacity. dimensional uniformity of crushed products.
08Heavy-load Self-aligning Bearing
We install heavy-load self-aligning bearings on two main shafts.
When a blade is impacted by a heavy load,the heavy-load self-aligning bearing produces an immense mechanical action that relieves the impact force.
We choose the world's leading bearings.of brands such as FAG and SKF as a standard configuration for all ENERPAT shredders.

Application

ENERPAT four shaft shredders, normally used for Plastics, Timber/Wood, Paper & Cardboard, Copper Cable, Aluminum, Textiles, Security Destruction, and Foam etc. They are available in different sizes and works perfectly in combination with other recycling machines. Each of the discs is made of alloy steel or furnished with a tool steel head. The discs can be replaced quickly thanks to the special shaft and blade design. The tool steel head is exchangeable quickly and without effort, which results in a significant reduction of tool changing times. The specific shape of the discs guarantees to crush material with little expenditure of energy, it makes the scrap-shredder to be durable.

Used Car
Rubber
Scrap Metal
Organic Garbage
E-waste
Waste Wood
Bulky Waste
Scrap Plastic
Municipal Solid Waste
Industrial Garbage
Medical Waste
Hazardous Waste

Crushing Effect

Used Oil Drums
Household Waste
Scrap Fabric
Waste Home Appliance
Sofa Mattress
Chemical Drums

Technical Specification

Four shaft shredder(Medium type)
Model	MSC-E900S	MSC-E900L	MSC-E1000S	MSC-E1000	MSC-E1000XL
Blade Diameter(mm)	Φ290	Φ290	Φ320	Φ320	Φ320
Shaft Speed(rmp)	15-25	15-25	15-25	15-25	15-25
Blade Thickness(mm)	25	25	40	40	40
Blade Quantity(pcs)	32*2	40*2	25*2	30*2	30*2
Shredding Chamber Size(mm)	900*800	900*1000	1000*1000	1000*1200	1000*1400
Motor Power(kw)	18.5*2	18.5*2	22*2	22*2	22*2
Machine Size(mm)	240015502500	260015502500	290017002800	310017002800	330017002800
Machine Weight(kg)	4700	5000	6600	7100	7600

Four shaft shredder(Heavy type)
Model	MSC-E1300S	MSC-E1300L	MSC-E1300XL	MSC-E1600S	MSC-E1600L	MSC-E1600XL
Blade Diameter(mm)	Φ430	Φ430	Φ430	Φ510	Φ510	Φ510
Shaft Speed(rmp)	10-25	10-25	10-25	10-25	10-25	10-25
Blade Thickness(mm)	50	50	50	50	50	50
Blade Quantity(pcs)	24*2	28*2	32*2	32*2	36*2	40*2
Shredding Chamber Size(mm)	1300*1200	1300*1400	1300*1600	1600*1600	1600*1800	1600*2000
Motor Power(kw)	302+152	302+152	302+152	452+302	452+302	452+302
Machine Size(mm)	410020003100	430020003100	450020003100	480023003600	500023003600	520023003600
Machine Weight(kg)	15600	16000	17000	22500	23700	25000

: “
